9031754 E5 Device View
2-19
Physical Device View
Accessing the Physical Device View
Table 2-8 describes the icon subviews accessible form the DEC GigaSwitch’s
Physical Device View.
Table 2-8. DEC GigaSwitch l Physical Device View- Module Icon Subviews
Menu Selection Description
Module Notes Opens the Module Notes View, allowing you to
write, save, and email notes about the highlighted
module.
Module Port Table Opens the Module Port Table View, which displays
the module’s number, its ports, the MIB II Index
and Bridge Ports.
Module Configuration Opens the Board Table view, allowing you to
change the DEC Gigaswitch’s status. NotPresent,
PowerDown, PowerUp, PowerDownTheUp,
Fault, RevMismatch, and SelfTestInProgress
are the status choices. For more information, refer
to Chapter 3, Configuration Views.
