DEC-Specific Applications

5-3

DecGigaApp

GigaSwitch ARP

In addition to these configuration settings, three buttons provide access to
tables detailing information on the boards within the GigaSwitch, the
hardware and firmware specifications for the GigaSwitch, and the
information on the GigaSwitch’s power supply.

This table provides information on individual boards in the GigaSwitch.
Information is categorized by Index, Type, Status, Hardware Revision, and
Firmware Revision. Double-clicking on an entry will access the Board Table
View. The Board Table View allows the user to choose the status of a
particular board. The following choices are available: NotPresent,
PowerDown, PowerUp, PowerDownThenUp, Fault, RevMismatch, and
SelfTestInProgress.

This table allows the user to choose to Heed or Ignore the temperature
warning, should the GigaSwitch overheat as well as detailing information on
the GigaSwitch hardware and firmware.

This table shows the Status, Input Source, and Output information for the left
and right power supply sources.

GigaSwitch ARP

ARP Agent
The user can specify whether the ARP Agent is on or off.

Timeout
The user can specify the timeout setting in seconds.

Period Between
The interval, measured in seconds, between the ARP Agent trying to resolve
an IP and MAC address.

Retries
The user can specify the number of times the ARP agent will try to reconcile
an IP and MAC address.

The GigaSwitch ARP table details the IF Index, Unicast Receive,
Broadcast Receive, Replies trns, Frames Flood
, and Frames Discarded
information for the GigaSwitch ARP.

Boards

PSC Controller

Power Supply
