Interface Device View
Device View
DEC GigaSwitch
2-16
Management Module Guide
Gauge Control Panel Buttons
Several buttons allow you to control the way the Gauge Control Panel
selections affect the logical interface icon. The Gauge control panel provides
the following buttons:
Apply the current selections to the Logical Gauge. The settings cannot be
saved.
Save the current gauge settings while running SpectroGRAPH.
Reset back to the last Keep Settings selections.
Close the Gauge Control Panel.
Reset back to the default attribute of Load.
Apply
Keep Settings
Reset
Close
Default
