Interface Device View

Logical Interface Icon

Device View

DEC GigaSwitch

2-10

Management Module Guide

The interface status label provides access to the status view specific to the
port. Double-clicking on this label opens the Interface Status view. This view
allows you to set the administrative status to ON or OFF.

Interface Configuration View/Port Type Label

The Port Type Label displays the type of DECGigaSwitch interface. Possible
interface types are shown in Table 2-4.

Double-clicking on the interface type label displays the Interface
Configuration view. This view allows you to set the Administrative Status of
the highlighted interface to On, Off, or Testing.

The Interface Configuration view also displays the interface’s Operation
Status, Physical Address, Bandwidth, Packet Size, Queue Length, Last
Change information as read-only values.

Table 2-3.

Interface Status Label Definitions

Operational

Status

Administrative

Status

Text Display

Color

ON

ON

ON

Green

OFF

OFF

OFF

Blue

OFF

ON

OFF

Yellow

TESTING

TESTING

TEST

Red

Table 2-4.

Interface Types for the DECGigaSwitch

Interface Type

Description

other

None of the following

regular1822

Regular 1822

hdh1822

HDLC Distant Host protocol

ddn-X25

Defense Data Network X.25

rfc877-x25

RFC877 X.25

ethernet-csmacd

Ethernet CSMA/CD

iso88023-csmacd

ISO CSMA/CD

iso88024-tokenRing

ISO token bus

iso88025-tokenRing

ISO token ring

iso88026-man

ISO man
