Interface Device View

Logical Interface Icon

Device View

DEC GigaSwitch

2-12

Management Module Guide

Network Information Panel/Network Information Label

The Network Information Label displays the name, address, or subnet mask
of this interface, according to selections made in the Interface Options Panel,
(see Interface Options Panel on page 2-8) .

Double-clicking on this label displays the Network Information Panel,
displaying the name, address, and subnet mask of this interface.

Interface Performance View/Logical Gauge Label

Double-clicking on this label of the Interface Icon allows you to access the
Performance View for the interface. You can also access this view by
highlighting the GigaSwitch icon and selecting Performance from the Icon
Subviews menu. This area is also a Logical Gauge, which is described later in
this chapter. The Performance view summarizes network traffic flow in
packets for this interface, providing the following information:

Multi-Attribute Line Graph
The Multi-Attribute Line Graph provides a general indication of network
activity. The attributes are pre-selected and use colors to represent different
statistics. For more information on the Multi-Attribute Line Graph, refer to
SPECTRUM Views. Table 2-5 lists the color and statistical definitions for
each attribute.

Table 2-5.

Color and Statistical Definitions for each Attribute

Statistic

Color

Description

%
Transmitted

White

The percentage of the total number of packets
that have been transmitted, device-wide, during
uptime.

% Discarded

Orange

The percentage of the total number of packets
that have been discarded, device-wide, during
uptime.

% Error

Red

The percentage of the total number of packets
that have contained errors, device-wide, during
uptime.

% Host
Bound

Yellow

The percentage of the total number of packets
that have been delivered to the local host from
the port during uptime.

In Packet
Rate

Light Blue

The total number of packets that have been
received, device-wide, during uptime.

Out Packet
Rate

Turquoise

The total number of packets that have been
transmitted, device-wide, during uptime.

Total Packet
Rate

Royal Blue

The total number of packets that have been
transmitted and received, device-wide, during
uptime.
