Logical Device View

Accessing the Logical Device View

Device View

DEC GigaSwitch

2-2

Management Module Guide

Accessing the Logical Device View

The Logical Device view is accessed using one of the following methods:

• Double-click on the Device view button of the Gigaswitch device icon. This

will open the Device view that was opened last (i.e. Logical, Physical, or
Interface).

• Highlight the DEC Gigaswitch device icon and select Device -> Logical

from the Icon Subviews menu.

Device View Button

Go Back
Go Up
Icon Subviews
View Path
New View
Bookmarks
View History
Current View Info...
Notes...
Jump by name...
Zoom
Map Hierarchy

Close
Navigate
Alarms
Performance
Notes...
Utilities
Zoom
Device
DevTop

Logical
Physical
Interface
