page 33
PULVERISETTE 25
5.3.2.2 Removing the Piston (23):
1. Open the funnel lid (21).
2. Use a screwdriver to unscrew the Phillips head screws (D).
3. Close the funnel lid (21).
4. Use a screwdriver to unscrew the Torx screws (E).
5. Unscrew the knurled screw (B).
6. The piston (23) can be taken out.
7. Reinstall in reverse order.
5.4 Collecting Vessel
Pull out and clean the collecting vessel (8). It can be vacuumed
out or wiped with a damp cloth.
After cleaning, check the function of the cutting mill. See
chapter 3.7 and 3.8.
Ensure that the parts are seated firmly during reassembly.
D
E
b
23
