page 22
PULVERISETTE 25
6. Close the cutting mill (see chapter 4.1.6)
Caution!
Check whether the rotor (3) turns freely (see chapter Fehler!
Verweisquelle konnte nicht gefunden werden.).
If this is not the case, do as described in chapter 4.1.3
Setting the Knife Gap Width
Perform this check every time the rotor (3) is changed!
4.1.5 Inserting / Changing a Sieve Cassette
1. Open the cutting mill (see chapter 4.1.1)
2. Pull out the sieve cassette (7) to the front; the rotor (3) does
not have to be removed.
To pull out the sieve cassette (7), it may be necessary to use
the pulling tool (X) 45.5550.10: Insert the pulling tool into the
two holes in the sieve cassette (7) past the bends in the
pulling tool. Lightly move the pulling tool up and down while
inserting it.
3. If the sieve cassette (7) is jammed, use a screwdriver to
remove the grinding material under stationary knife 3 (9) on
the left side of the housing.
4. Before inserting the sieve cassette (7) clean the cutting
chamber thoroughly so that the machine can be closed tightly
again.
5. Close the cutting mill (see chapter 4.1.6)
4.1.5.1 Choice of Sieve Cassette
Coarse pieces of material should be predominated with a coarse
sieve 2-4 mm and comminute to the desired final fineness in a
second grinding step.
C
X
