40 G730
G730 ® TRANSAXLE PARTS LIST
1 Housing, Main
2 Housing, Side
4 Plug 9/16-18 (metal)
7 HFHCS 1/4-20 x 1.25”
10 Seal, Lip .625 x 1.0
20 Center Section
22 Plate, bypass
23 Filter, Oil
24 Check Plug or Shock Valve
25 Check Plug or Shock Valve
26 Seal, Plug 1.250 x .250
27 HFHCS 3/8-16 x 1.5 (Patch)
30 Seal, Lip .375 x .75 x .25
31 Ring, Retaining .375 External
32 Rod, Bypass
33 Ring, Retaining .750 Internal
34 Arm, Bypass
35 Ring, Retaining .375 External
40 Trunnion, Swashplate
41 Seal, Lip 18 x 32 x 7
44 Arm, Control
45 Washer .34 x .88 x .06
46 TWHCS 5/16-24 x 1.00 (Patch)
52 Input Shaft
53 Bearing, Ball 17 x 40 x 12
54 Ring, Retaining Wire .561 I.D.
55 Washer 1.23 x 1.56 x .04
56 Seal, Lip 17 x 40 x 7
57 Ring, Retaining 2.06 Internal
60 Bearing, Thrust
64 Cylinder Block (Motor)
65 Bearing, Thrust Ball 30 x 52 x 13
69 Cylinder Block (Pump)
70 Washer .63 x 1.0 x .05
71 Ring, Retaining .625 External
72 Gear, Reduction 14T
73 Shaft, Motor
74 Washer .72 x 1.16 x .04
80 Washer .5 x 1.0 x .03
81 Gear, Reduction 45T
82 Gear, Reduction 11T
83 Pin, Jack Shaft
90 Ring, Retaining 2.06 Internal
91 Gear, Bull 60T
92 Spacer, 1.04 x 1.65 x .22
94 Shaft, Axle
95 Bearing, Ball 1.0 x 52 x 15
96 Seal, Lip 25 x 52 x 10 TC (Gray)
105 Screw, Hex Flange Head 1/4-20 x .75
106 Guard, Filter
115 Damper
116 Bracket, Damper
117 Stud, Threaded Ball
118 Washer, Lock 5/16
119 Hex Nut, 5/16
120 Fan
121 Pulley
122 Hex Lock Nut 1/2-20 (Nylon Insert)
123 Screw 1/4-20 x .875
123 Washer, OD Slotted
130 Tube, Connecting
131 Gerotor Assembly (1.9 CC/rev)
132 O-Ring, -137, 0.103 x 2.050
133 Cover, Charge Pump
134 Screw, Hex Flange Head 1/4-20 x .75
135 Ball Steel 7/16”
136 Spring, Relief .42 x .75
137 Pin, Spring .125 x .875
140 Spacer .320 x 1.005 x .179
141 Arm, Neutral
142 SHCS 5/16-24 x 1 Patch
145 Assembly, RTN Bidirectional
146 Washer, .343 x 1.500 x .062
147 Spring, Extension
152 Gear, Bevel 14T spline ID
153 Gear, Bevel 10T
154 Pin, .499 x 1.20
155 Ring, Spiral Retaining - 87
156 Retainer, Switch
157 Rivet, 5/32
158 Switch, RCS
159 Clip Actuator
170 Puck, Brake
171 Rotor, Brake
172 Plate, Puck
175 Bolt, Hex Head 1/4-20 x 1 w / patch
176 Bolt, Hex Head 1/4-20 x 2 w / patch
177 Pin, Brake .31 x .73 Plated
178 Spring, Comp Brake Anti-Drag
179 Arm, Brake
181 Nut, Castle 5/16-24 PL
182 Pin, Cotter 3/32 x 3/4
183 Spacer .26 x .57 x .87
184 Washer .27 x .88 x .12
185 Spring, Brake Arm Bias
191 Hose
200 Kit, Seal
201 Kit, Center Section
202 Kit, Charge Relief
203 Kit, Charge
207 Kit, Fan & Pulley
210 Kit, Input Shaft
212 Kit, Brake Yoke
214 Kit, ROS
215 Kit, RTN
216 Kit, Breather
217 Kit, Bypass Arm
218 Kit, Filter Guard
219 Kit, Damper
