Transmission Overhaul
35
10e. Slide the spring onto the wheel shaft so that it
is next to the clutch collar.
10f. Slide the washer onto the wheel shaft so that it
is against the spring.
10g. Install the third snap ring while compressing the
spring and washer. See Figure 6.22.
11. Slide the shift fork into the groove in the clutch collar.
See Figure 6.23.
12. Slide the wheel shaft assembly into the transmission
housing.
NOTE: Do not install the wheel shaft bearings at this time.
13. Install the tapered roller bearings onto both ends of
the drive shaft.
14. Slide the drive shaft into the transmission housing
from the rear opening.
15. Apply a 3/16” (4.75mm) bead of Threebond ® 1217H,
Permatex ® Ultra Black #82180 or equivalent sealant
on the side cover..
16. Install the side cover. Tighten the screws to a torque
of 110 - 125 in lbs (12 - 14 Nm).
17. Install the left side wheel shaft bearing.
18. Install the snap ring that retains the left wheel bearing
using a pair of snap ring pliers.
19. Install the right wheel shaft bearing.
20. Install the snap ring that retains the right wheel bear-
ing using a pair of snap ring pliers.
21. Install a new shift fork oil seal. See Figure 6.24.
Figure 6.22
Spring
Washer
Clutch collar
Snap ring
Figure 6.23
Shifter fork
Figure 6.24
shifter fork oil seal
