- 16 -
3.5 Setup of the Baud Rate
As shown in the Figure, SW2 is used to set the protocol of communication and the baud rate used
by the dome camera. DIP-6 and DIP-5 of SW2 are used to select the baud rate of communication and
4 different baud rates can be selected in maximum. If the controller adopts non-standard baud rate,
you can adjust it to be identical with that of the main machine as per the following table.
Baud Rate of Communication DIP-1 DIP-2 DIP-3 DIP-4
Setup of Baud Rate
DIP-5 DIP-6
2400 bps OFF OFF
4800 bps ON OFF
9600 bps OFF ON
19200 bps ON ON
3.6 Selection of the Terminal Resistor
As shown in the Figure, sw 1is the select switch of the 120
Ω terminal resistor on the bus
RS485, on which only one terminal resistor of the dome camera at the farthest end can be
connected, while the terminal resistors of other devices should be opened.
3.7 Special Control (the SHORTCUT item must be ON in the menu)
NO Set Preset Call Preset
1 Reserved Tow Preset Open the menu
64 Reserved Open the menu
65 Reserved Run patrol 1
66 Reserved Run patrol 2
67 Reserved Run scan 1
68 Reserved Run scan 2
69 Reserved Run pattern 1
70 Reserved Run pattern 2
