C-650 Operation Manual, Version B 8 Troubleshooting 49
NOTE
If the nebulizer cleaning procedure does not solve the problem, contact your local distributor for
a nebulizer replacement.
In case the black gas tubing has been removed, make sure you are using the correct orientation,
where the white one-way valve is at the lower end (near the gas arrival). Avoid leaks at all con-
nections and check for possible leakage when you turn the pump on again.
1
2
3
4 6
7
5
a Siphon overflow
b Gas one-way valve
c Gas inlet fitting
d Nebulizer e Nut
f Glass chamber
g Nut
Fig 8.30: Installing the nebulizer/glass chamber assembly
8.6 Gas flow problems
In case of gas flow problems, please contact the BUCHI Customer Service.
8.7 Cleaning and decontamination
8.7.1 Device cleaning
CAUTION
Risk of minor burns by hot detector.
• Let the detector cool down safely for 15 minutes before cleaning.
• Switch the device off.
• Disconnect all connection cable (power cable, signal cable, autozero cable, RS-232 cable if
any, device gas input and nebulizer tubing).
• Clean the outside of the detector with a non-abrasive cloth. If necessary, a liquid such as
soapy water or ethanol can be used to remove stains or foreign material.
