C HAPTER 4 | Initial Configuration
Setup Wizard
– 42 –
◆ Default Gateway — The IP address of a router that is used when the
requested destination IP address is not on the local subnet.
◆ Operation Mode — Enables and configures the keep alive time.
◆ Primary DNS Server — The IP address of the Primary Domain Name
Server. A DNS maps numerical IP addresses to domain names and can
be used to identify network hosts by familiar names instead of the IP
addresses. To specify a DNS server, type the IP addresses in the text
field provided. Otherwise, leave the text field blank.
◆ Secondary DNS Server — The IP address of the Secondary Domain
Name Server.
◆ MAC Clone — Some ISPs limit Internet connections to a specified MAC
address of one PC. This setting allows you to manually change the MAC
address of the 11n Router’s WAN interface to match the PC’s MAC
address provided to your ISP for registration. You can enter the
registered MAC address manually by typing it in the boxes provided.
Otherwise, connect only the PC with the registered MAC address to the
11n Router, then click the “Clone your PC’s MAC Address” (Default:
Disable)
S TEP 4 - W IRELESS
S ECURITY
The Step 4 page of the Wizard configures the wireless network name and
security options.
Figure 21: Wizard Step 4 - Wireless Security
The following items are displayed on this page:
◆ SSID Choice — The name of the wireless network service provided by
the 11n Router. Clients that want to connect to the network must set
their SSID to the same as that of the 11n Router. (Default: “ALFA”)
◆ Security Mode — Specifies the security mode for the SSID. Select the
security method and then configure the required parameters. For more
