Hardware Description
– 20 –
Figure 2: Rear Panel
LED I
NDICATORS
The 11n Router includes eight status LED indicators, as described in the
following figure and table.
Figure 3: LEDs
RJ-45 WAN Port
RJ-45 LAN Ports
Reset Button
DC Power
Socket
WPS Button
LAN 1~4
WLAN
Power
WAN
WPS
