ALFA NETWORK AIP-W505 - Manual (Page 119)

– 119 –
B
H
ARDWARE
S
PECIFICATIONS
P ORT I NTERFACES
WAN: 1 10/100BASE-TX port, RJ-45 connector, auto MDI/X
(100-ohm, UTP cable; Category 5 or better)
LAN 1~4: 1 10/100BASE-TX port, RJ-45 connector, auto MDI/X
(100-ohm, UTP cable; Category 5 or better)
AC P OWER A DAPTER
Input: 100~240 VAC, 50/60 Hz
Output: 5 V/ 1 A
LED I NDICATORS
Power, WLAN (Wireless Local Area Network), WPS
(Wi-Fi Protected Setup), WAN (Wide Area Network), LAN 1~4 (Local Area
Network).
N ETWORK M ANAGEMENT
Web-browser
T EMPERATURE
Operating: 0 to 40 °C (32 to 104 °F)
Storage: -20 to 70 °C (32 to 158 °F)
H UMIDITY
20% to 85% (non-condensing)
P HYSICAL S IZE
136 X 90.8 X 28.5 mm
W EIGHT
157 g (5.54 oz)
R ADIO
FCC Part 15C (Section 15.247)
EN 301 489-1 V1.8.1 (2008-04)
EN 301 489-17 V1.3.2 (2008-04)
EMC FCC Part 15B
EN 55022:2006 + A1:2007
EN 55024:1998 + A1:2001 + A2:2003
