C HAPTER 10 | Administration Settings
System Log
– 115 –
◆ Tx bytes — Displays the total number of bytes transmitted by the
specified interface.
S YSTEM L OG
The 11n Router supports a logging process that controls error messages
saved to memory or sent to a Syslog server. The logged messages serve as
a valuable tool for isolating 11n Router and network problems. The System
Log page displays the latest messages logged in chronological order, from
the newest to the oldest. Log messages saved in the 11n Router’s memory
are erased when the device is rebooted.
Figure 71: System Log
The following items are displayed on this page:
◆ System Log — Displays the latest log messages in chronological order,
from the newest to the oldest.
◆ Refresh — Sends a request to add the latest entries to the System Log
Table.
◆ Clear — Removes the current system log messages from the System
Log Table.
