Operations
1 , 5
It is possible to view the video picture on your TV in the
same way that you watch TV broadcasts.
If you have connected the VTR to the TV through the
video and audio input sockets then you do not need to
follow the procedure mentioned below.
Display Symbols
1
Turn on the TV and VTR.
OPERATE
2
VTR/TV j
o I
Select the VTR mode.
VTR
3
H
1=1
L
Select the video playback channel which is
not occupied with any TV station.
NV-SD10A: L (channel 0) or Fi (channel 1)
NV-SDIOEA: L (channel 2) or H (channel 3)
4
03
O l i o N
TEST
SIGNAL
To generate a test pattern, set TEST
SIGNAL to ON.
Vjr'
ID
Set the TV to an unused position which you
wish to use for your video playback.
NV-SDIOA:
L (channel 0) or H (channel 1)
NV-SDIOEA; L (channel 2) or H (channel 3)
• NV-SD10A only
In some areas channel 0 may be used by local TV station.
In this case switch to channel 1.
93
OFF ON
TEST
SIGNAL
Set
TEST SIGNAL
to OFF.
