Connector Signals
S-VIDEO IN/OUT Connectors
Pin No.
Description of signal
1
YGND
2
CGND
3
Y signal
4
C signal
Model AG-71 SO is not equipped with S-ViDEO IN Connector.
34P REMOTE Connector
Pin No.
10
11
12
13
14
15
16
Description of signal
REC SWITCH
PLAY SWITCH
FF SWITCH
REW SWITCH
STOP SWITCH
AUDIO DUB SWITCH
PAUSE SWITCH
CASSETTE IN
AUDIO DUB SWITCH
GND
FRAME ADV. SWITCH
REVERSE COUNT
EDIT SWITCH
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
REVERSE
CONTROL PULSE OUT
REMOTE 19
START MARK
EJECT SWITCH
REC HOLD
PLAY HOLD
FF HOLD
REW HOLD
AUDIO DUB HOLD
PAUSE HOLD
REMOTE 30
AUDIO DUB HOLD
REMOTE 33
+ 12 V
Pin No. 1,6,9, 23,28 and 31 are not used for model AG-7150.
