Search Operations

Press the SEARCH Button.

The SEARCH, PLAY and PAUSE/STILL Buttons’ indicators will

light up. Then the unit goes into the SEARCH standby mode.

Operate the SEARCH/JOG Dial.

The inner part dial is JOG mode while the outer part dial is
SHUTTLE mode.

■ When the SEARCH/JOG Dial is rotated clockwise, the tape

will be played back in the forward direction {the FWD in
dicator appears). When it is rotated counterclockwise, the
tape will be played back in the reverse direction (the REV in
dicator appears).

[1] JOG mode

In response to the speed at which the inner part dial is

turned, the tape can be played back at a speed ranging
from still picture to ±1 x normal tape speed.

When the turning is stopped, a still picture is always pro
duced.

[2] SHUTTLE mode

When the outer part dial is rotated in the SHUTTLE mode,
the tape speed will be changed depending on the position
of the SEARCH/JOG Dial, The tape speed can be
changed from 0 (ie, STILL playback) to 9 times the normal
tape speed.
The still picture is obtained when the SEARCH/JOG Dial is
set to the center fix position (click-stop).

'«

Note

Set the “DIRECT SEARCH" mode in the ON-SCREEN (initial setting) menu to "ON" to perform the direct search

operation. (Refer pages 38 to 41.)
