ON-SCREEN (Initial Setting)
(CONT’D)
Contents of each initial setting item
DATA Button:
To select operation mode
DOWN Button:
To move to the next item
SHIFT Button:
To shift to next menu screen
0
z
1
(O
o
X
m
m
z
Superimpose
AUDIO LIMITER
{AG-7350 onty)
DOLBY NR
AUDIO CH2
AUDIO DUB
(AG-7350 only)
HIFI REG
(AG-7350 only)
S-VHS
(AG-7350 only)
EDIT
NOTCH
Description
Of
function
Sets the AUTO LIMITER function ON or OFF.
ON:
Permits audio recording with less distortion at peak levels with the aid of
the automatic volume control circuit. (This function is activated when
normal audio recording is performed.)
OFF:
Permits maximum dynamic range to be recorded, but the level must be
set low enough so that peaks do not cause objectionable distortion.
Sets the DOLBY NR function ON or OFF.
ON:
Dolby NR system is activated.
OFF:
Dolby NR system is not activated.
■ DOLBY Noise Reduction System
\PLAY
ON
OFF
REC\
ON
Normal sound with less
Treble is emphasized.
noise.
OFF
Treble is attenuated.
Normal sound
'DOLBY NR system is activated when normal audio is reproduced.
Selects the signal to be recorded or played back on audio channel 2.
AUDIO:
Audio signal is recorded/played back.
TIME CODE:
Time code signal is recorded/played back. (Sound track of
channel 2 will be muted.)
Selects the audio track CHI or CH2 for audio dubbing.
CHI
:
Audio is recorded on channel 1.
CHI, CH2:
Audio is recorded on both channels 1 and 2.
CH2:
Audio is recorded on channel 2.
Initial mode
OFF
OFF
AUDIO
Sets the Hi-Fi audio recording.
ON:
Hi-Fi audio is recorded.
OFF:
Hi-Fi audio is not recorded.
Sets the recording mode.
ON:
Distinguishes between the VHS and S-VHS tapes and determines the
recording mode.
OFF:
VHS recording is performed.
Sets the editing mode.
ON:
To edit or duplicate tapes (dubbing)
OFF:
For normal operation
VIDEO MODE Selects the colour mode of video input signal.
COLOUR:
Forcibly colour mode
AUTO:
Automatically distinguishes between black & white and colour video
input signals.
Forcibly black & white mode
Selects whether to reduce noise or not.
ON:
When noise appears during composite input.
OFF:
When noise do not appear during composite input.
CH1,CH2
ON
ON
OFF
AUTO
ON
