Electrical Connections
Caution:
• This product is designed to operate with a 12 V DC, negative ground battery system.
• To prevent damage to the unit, be sure to follow the connection diagram below.
• Remove approximately V4" {5 mm) of protective covering from the ends of the leads before connecting.
• Do not insert the power connector into the unit until the wiring is completed.
• Be sure to insulate any exposed wires from a possible short-circuit from the car chassis. Bundle all cables
and keep cable terminals free from touching any metal parts.
• Remember, if your car has a drive computer or a navigation computer, the data of Its memory may be
erased when the battery terminals are disconnected.
□ Wiring Diagram
Antenna
External amplifier control lead ^--------------------------------------------
{Max. 500 mA)
This lead is for connection to the power amplifier.
"Note! '
• This lead is used for power control when an external power
amplifier is connected. The power supply of a power amplifier
will be activated when turning on the power of this unit.
(Blue/white stripe)
Not used.
Note:
• Insulate this lead with vinyl tape.
(Brown/white stripe)
Motor antenna relay control lead ^------------------------------------------
(To motor antena) (Max. 500 mA)
This lead is not intended for use with switch actuated power antenna.
Note:
• The power antenna extends automatically when the AM/FM
radio mode is selected.
(Dark blue)
ACC power lead ^—
To ACC power, -I-12VDC.
Battery lead <------------------------------
To the battery, continuous - h 12 V DC.
Register (1 kO)
— A C C "
Zl=
(Red)
Fuse (15 A)
~lzz| BATTERY 15 A h
(Yellow)
Ground lead ^-------------------------------------------
To a clean, bare metallic part of the car chassis. (Black)
