Panasonic KVS2055L - Manual (Page 41)

Specifications
Item
Model No.
KV-S2055L KV-S2055W
Scanning face Duplex scanning
Scanning method
Front side : CIS (Contact Type Image Sensor)
Back side : CIS (Contact Type Image Sensor)
Readout speed
Simplex scanning : Approx. 50 sheets/min.
(Letter, fed lengthwise, 200 dpi)
Duplex scanning : Approx. 50 sheets/min.
(Letter, fed lengthwise, 200 dpi)
Resolution
Main scanning direction : 100'^ 600dpi (1 dpi step)
Sub-scanning direction : 100 ~ 600dpi (1 dpi step)
(Same as main scanning direction)
The optical resolution is 400 dpi.
Scanner
Tonal gradation
Binary mode. Grayscale mode (4/8 bit), 64-step gradation
(dither) mode, 64-step gradation'(error diffusion) mode
Image control
Image emphasis. Automatic threshold. Automatic separation.
Monochrome reversing. Automatic back control
Paper
Size
Scanning size :
48 x70mm (1.9x2.75 in.) to
216X431 mm (8.5X 17 in.)
Feeding size :
48 X 70mm (1.9x2.75 in.) to
305 x838mm (12x33 in.)
Scanning size :
48 X 70mm (1.9x2.75 in.) to
298x431mm (11.7X17 in.)
Feeding size
48 X 70mm (1.9x2.75 in.) to
305x838mm (12x33 in.)
Thickness
Single paper feeding : 0.025 to 0.2mm (1.0 to 7.9 mils)
Continuous paper feeding : 0.06 to 0.2mm (2.4 to 7.9 mils)
Note : 1 mil = 1/1000 in.
Weight
Single paper feeding : 20 to 157 g/m (5.3 to 42 lbs.)
Continuous paper feeding : 50 to 157 g /rn (13 to 42 lbs.)
External dimensions
(Width X Depth x Height)
495x575x246mm (19.5x22.6x9.7 in.)
Mass (Weight) 19kg (41.8 lbs.)
Unit
Power requirement AC100-120V, 50/60HZ
Power
Maximum
(Scanning)
1-3A . . . .
consumption
Minimum
(Standby)
0.5A
Operating .
Environment
Operating temperature
and humidity
15“C to 30“C (59T to 86T), 30% to 80%RH
Storage
Environment
Storage temperature
and humidity
0°C to 35°C (32T to 95T), 10% to 80%RH
Option
Roller exchange kit (KV-SS009), Imprinter option (KV-SS010),
Roller cleaning paper (KV-SS03), Ink cartridge (KV-SS06)
'Weight in pounds" of paper represents the weight of 500 [17x22 inches (432x559mm)] sheets.
41
