Replacing Consumable
6
Push up on the paper feed roller
block and it will magnetically
attach to the chassis.
• When attaching the paper feed roller
block to the chassis, do not damage
the roller.
• You are now finished attaching the
paper feed roller module.
To continue, replace the retard roller
module according to the following
procedure. (The retard roller module
Is located in the conveyor.)
7 Pull open the conveyor towards
you by using the indent on the
right side.
• When the conveyor is pulled towards
you, the click-stop mechanism will be
released.
• When opening the conveyor, be
careful not get your finger stuck in
the indent.
8 Pull the right side of the shaft in
the direction of the arrow and
hold it there. (®)
Pull the retard roller module in the
direction of the arrow ((D) and
then remove it.
37
