Front panel controls
0 Disc select buttons and indicators (DISC 1-DISC 5)
® Power "STANDBY O/ON" switch
(POWER, STANDBY (!)/ON)
Press to switch the unit from on to standby mode or vice \’ersa. li
standby mode, the unit is still consuming a small amount of po\\'er
(3) Disc tray
(D Super woofer level select button (LEVEL)
(D Super woofer ON/OFF button (SUPER WOOFER)
(6) Display
(7) Karaoke button (KARAOKE)
d) Microphone volume control (MIC VOL)
(D Echo volume control (ECHO)
(1§) Microphone jack (MIXING MIC)
(0) Deck 1 cassette holder
@ Disc tray open/close button (± OPEN/CLOSE)
® Disc check open button (OPEN, -NEXT/-AUTO)
(Q) CD manager button (CD MANAGER)
® Random play button (RANDOM)
® 3D space EQ button (3D SPACE EQ)
(0) Muting button (MUTING)
@ Volume control (VOLUME)
® Headphone jack (PHONES)
Deck 2 cassette holder
@ Tape/deck select button (TAPE, DECK 1/2)
(g) CD button (CD)
® Tuner/band select button (TUNER/BAND)
@ AUX button (AUX)
@ Display select/demonstration button
(-DISPLAY/-DEMO)
(g) Clock/timer button (CLOCK/TIMER)
@ Play timer/record timer button (©PLAY/OREC)
@ Basic operating buttons
Buttons change according to the source,
(g) Deck 1 open button (DECK 1, ^ OPEN)
® Tape edit button (TAPE EDIT)
(|i) Recording start/stop button (• REC/STOP)
® Dolby noise reduction button (DOLBY NR)
® Reverse mode select button (REV MODE)
@ Deck 2 open button (DECK 2, A OPEN)
