Technical specifícafions
AMPLIFIER SECTION
RMS power output
THD 10%, both channels driven
LOW
HIGH
Total BI-AMP power
PMPO
Total harmonic distortion
Half power at 1 kHz
Input sensitivity and impedance
AUX
MIC
Tone controls
6 EQ SPACE HEAVY, CLEAR,
Load impedance
92 W per channel (6 ii)
38 W per channel (6 ii)
130 VV per channel
2000 W (6 ii)
LOW 0.03 "/<. (6 ii)
HIGH 0.15 'Ii. (6 ii)
250 mV, 57 kii
0.6 mV, 680 ii
SOFT, HALL, LIVE, DISCO
6ii
FM TUNER SECTION
Frequency range
Sensitivity
Total harmonic distortion
MONO
STEREO
S/N
MONO
Image rejection at 98 MHz
Stereo separation at 1 kHz
Antenna terminal(s)
AM TUNER SECTION
Frequency range
Sensitivity (for 500 mW)
(at 999 kHz)
CASSETTE DECK SECTION
Track system
Heads
Record/playback
Erasure
Motor
Recording system
Erasing system
Tape speed
Frequency response
[(+3 dB, -6 dB) at deck out]
NORMAL
HIGH
(HIGH)
Dolby NR off
Dolby NR on
Wow and flutter
Fast forward and rewind time
CD SECTION
Sampling frequency
Decoding
Beam source/wave length
Number of channels
S/N
CD UNIT OUT
Wow and flutter
Digital filter
0/A converter
87.50-108.00 MHz {50 kHz steps)
23.3 dBf (4.0 pv, IHF'58)
0.3 %
0.5 %
60 dB
35 dB
35 dB
75 ii (unbalanced)
531 - 1602 kHz (9 kHz steps)
530 - 1600 kHz (10 kHz steps)
250 pV/m
4 track, 2 channel
Solid permalloy head (Rotary head)
Double gap ferrite head
DC servo motor
AC bias 100 kHz
AC erase 100 kHz
4.8 cm/s
35 Hz - 14 kHz
35 Hz - 14 kHz
50 dB (A weighted)
60 dB (CCIR)
0.18 % (WRMS)
Approx. 120 seconds
with C-60 cassette tap«
44.1 kHz
I 16 bit linear
Semiconductor laser/780 nm
Stereo
95 dB aiS.A)
, Below measurable limit
8 fs
MASH {1 bit DAC)
SPEAKER SECTION
Type
Speaker(s)
Super Woofer
Woofer
Midrange
Tweeter
Impedance
Input power
Output sound pressure level
Cross over frequency
Frequency range
Dimensions (WxHxD)
Weight
4 way speaker system
17 cm cone h’pe
12 cm cone type
6 cm cone ty'pe
6 cm cone type
HIGH (6ii), LOW (6ii)
HIGH 80 W (MUSIC), 40 W (DIN)
LOW 200 W (MUSIC), 100 W (DESI)
87dB/W (1.0 m)
120 Hz, 4 kHz, 8 kHz
38 Hz-22 kHz (-16 dB)
45 Hz-20 kHz (-10 dB)
285 X 345 X 326 mm
6.2 kg
GENERAL
Power consumption 165 W
Power supply AC 110 V/127 V/220 V/230-240 V, 50/60 Hz
Dimensions (WxHxD) 270 x 345 x 314 mm
Weight 8.25 kg
Notes:
1. Specifications are subject to change without notice.
Weight and dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
MASH is a trademark of NTT.
Prepare the system as described below to prevent damage to the
mechanism.
1. Remove all CDs.
2. Press CD.
3. Press ■ for 5 seconds.
The display will change from "WAIT" to "LOCKED" to "GOOD
BYE" and finally "7.77" Then, the unit will be turned OFF
automatically. (This will set the so-called "shipping mode".)
4. Unplug the stereo.
The shipping mode will turn OFF automatically when you turn
the power ON the next time.
