VCR Plus+ Set Up

This setup is for VCR Ptus+ and timer
programming only.

VCR Plus+ programming allows you to set most items of a timer recording by simply entering a special code found in

TV GUIDE

magazine as well as the TV listings in selected newspapers. In order for the VCR to read this special code, some set up is required.

A Guide (VCR Plus+) channel number is assigned to each local broadcast and cable station. Because this number sometimes

differs from the channel your TV receives the station on, it is necessary to program the VCR with local channel information.

NOTE: Complete the steps on this page if you are using
Connection Method 2 on page 10 for VCR hookup.

Prepare a list like the example below.

This list will help you smoothly enter the information

needed in step 4 at right.

You will need the following to complete the list:

■ A line up of normal and/or cable stations you

receive along with the channel numbers your TV
receives them on. A cable channel line-up chart is
supplied by your cable company.

■ A list of Guide (VCR Plus+) channel numbers

assigned to the stations you receive. This list is
available in TV Guide and the TV listings found in
selected newspapers.

Make a chart with 3 columns like the example

below. In the left column, fill in the name or call
letters of the stations you receive.

In the middle column, fill in each station's

assigned Guide (VCR Plus+) number found in TV
Guide, newspapers, etc.

In the right column, fill in the channel number that

your TV receives the station on from your channel
line-up.

EXAMPLE ONLY

Broadcast or Cable

Station Name

Assigned

Guide

(VCR Plus+)

channel no.

Channel no.

your TV

receives the

station on

HBO

Nickelodeon

CBS

FOX

VCR Plus+ Channel Set Up

(Connection Method 2 on page 10)

Push MENU

to display the

menu.

------------------- MENU .........................

SET UP VCR
SET CLOCK

Rotate and push

the WHEEL to

select SET UP

CHANNEL.

SET UP CHANNEL

IDIOMA/LANGUE:ENGLISH

SELECT
SET
END

ROTATE WHEEL
PUSH WHEEL
PUSH MENU KEY

Rotate and push

the WHEEL to

select VCR PIus-i-

CH SETUP.

--- SET UP CHANNEL ---

ANTENNA SYSTEM : CATV
AUTO SET
CABLE^/DSS BO. .SET. UP

SELECT
SET

END

ROTATE WHEEL
PUSH WHEEL
PUSH MENU KEY

IMPORTANT NOTE:

For this step, use the list you prepared. You may leave lines
blank if, you don’t receive that station, or the GUiDE CH
number and the CATV (or TV) CH numbers are the same.

Push WHEEL

to move the

shaded area on

the right side.

VCR Plus* CH SET UP

GUIDE CH CATV CH

-»

SELECT :

ROTATE WHEEL

SET

PUSH WHEEL

END

PUSH MENU KEY

)

Then, rotate the Wheei

to change CATV or TV CH number.

Next, push the Wheei

to enter CATV or TV CH number.

Now, rotate the Wheel

to continue.

Repeat this operation until the list is complete.

To Make Corrections

Rotate and push the Wheel to select the incorrect CATV or TV

CH number. Then, Push CLEAR to delete the numbers.

Now, use the Wheel to re-enter the channel.

Push MENU

twice to exit the

VCR Plus-k CH

SET UP mode.

Make your entries within 60 seconds or the VCR will
leave this mode.

Once local channels have been programmed, they will
stay in memory, even in the case of a power failure.

VCR Plus+C^and PlusCode are trademarks of Gemstar
Development Corporation. The VCR Plus+ system is manufactured
under license from Gemstar Development Corporation.
