Panasonic OMNIVISION PV-S4670 - Manual (Page 15)

To Change On Screen Display Language
1 Push MENU to display the menu.
Rotate the Wheel to select the
language selection item.
(English: LANGUAGE, Spanish:
IDIOMA, French: LANGUE).
.................. - MENU .......................
SET UP VCH
SET CLOCK
SET UP CHANNEL
lUIM’FjrJBiMIB: ENGL ISH
select
SET
END
ROTATE WHEEL
PUSH WHEEL
PUSH MENU KEY
3 Push the Wheel to change the language.
• Each Push will change the language in the order shown.
I—►English -►Spanish ► French—[
4 Push MENU to exit this mode.
To Add or Delete a Channel
Select a channel using the
NUMBERED keys .
CHANNEL 08 DELETED
I
ADDED
Push ADD/DLT to add or
delete the channel.
• To select a deleted channel,
use the NUMBERED keys
on the remote control. Deleted channels will flash
in the Multi Function Display when selected.
When Using the 100 key
When selecting CATV channels 100 to 125 with the
NUMBERED keys, first push the 100 key and then
enter the remaining two digits.
For example, to select channel 125:
Push NUMBERED keys 100, then 2, then 5.
To Set or Reset the Clock
In case the clock is wrong, or a power failure occurred.
1 Push MENU to display the menu.
2 Rotate and push the Wheel to;
(A) Select SET CLOCK
(B) Select MANUAL SET
(C) Set the date, time, and
D.S.T. (Daylight Saving
Time).
3 Push MENU twice to start the
clock and exit this mode.
MENU.....................
SET UP VCR
SET UP CHANNEL
ID10МА/ LANGUE : ENGL t SH
.......... SET CLOCK ................
AUTO SET
SELECT
SET
END ROTATE WHEEL
PUSH WHEEL
PUSH MENU KEY
SET CLOCK...............
ЙЕШЕНН
OSTiON
30Stt52nil
BY ROTATING WHEEL
4-PUSH CLEAR: :PUSH WHEEL-»
TO START PUSH MENU KEY
To Set or Reset Auto Clock Set
Complete the following steps if:
• Auto clock set displayed time was incorrect.
• Auto clock set was not available at the time one
time setup was done, but is available now.
• The PBS channel over which clock data is sent
was changed by the broadcast company.
Push MENU to display the menu.
2 Rotate and push the Wheel to
select SET CLOCK and then
select AUTO SET.
3 Follow the one time setup
instructions on page 12-14.
--------- SET CLOCK..................
MANUAL SET
SELECT
SET
END
ROTATE WHEEL
PUSH WHEEL
PUSH MENU KEY
To Replace Channels In Memory
Example, if you have cable installed, etc.
To setup the VCR In case a cable box or
DSS receiver was installed or replaced
1 Push MENU to display the menu.
2 Rotate and push the Wheel to
select SET UP CHANNEL from
menu, and then push to set
your antenna system (TV or
CATV).
3 Rotate and push the Wheel to
select AUTO SET.
• To exit this mode, push MENU
twice.
.................. MENU ........................
SET UP VCR
SET CLOCK
SET UP CHANNEL
ID10МА/LANGUE:ENGL ISH
SELECT
SET
END
ROTATE WHEEL
PUSH WHEEL
PUSH MENU KEY
--- SET UP CHANNEL ---
: CATV
AUTO SET
CABLE/DSS BOX SET UP
VCR Ptus-f CH SET UP
SELECT : ROTATE WHEEL
SET : PUSH WHEEL
END ; PUSH MENU KEY
4 Follow the one time setup
instructions on page 12-14.
• Whenever channels are replaced in memory, auto
clock set is also reprogrammed.
1 Push MENU to display the menu.
2 Rotate and push the Wheel to
select SET UP CHANNEL from
menu.
3 Rotate and push the Wheel to
select CABLE/DSS BOX SET UP.
• To exit this mode, push MENU
twice.
4 Rotate and push the Wheel to
select YES and continue with
steps 5-10 on pages 12 and 13.
.................... MENU .....................
SET UP CHANNEL
1DIОМД/LANGUE: ENGL I SH
SELECT : ROTATE WHEEL
SET : PUSH WHEEL
END L PUSH MENU KEY
SELECT
SET
END
--- SET UP channel ---
ANTENNA SYSTEM : CATV
AUTO SET
CABLE/DSS BOX SET UP
VCR Plus-I- CH SET UP
ROTATE WHEEL
PUSH WHEEL
PUSH MENU KEY
- CABLE/DSS BOX SET UP -
ARE YOU USING A CABLE
BOX OR DSS RECEIVER?
NO
SELECT : ROTATE WHEEL
SET : PUSH WHEEL
END ; PUSH MENU KEY
This VCR will accurately maintain its calendar up to Dec. 31,2014,11:59PM.
Normal TV or Cable channels are automatically selected and placed in memory depending on how your VCR is hooked up.
By pushing the Wheel or CLEAR button repeatedly, you can skip forward or backward over correct entries and go
directly to a specific item.
15
