Record On a Tape
Check list before you begin.
All connections are made.
(See pages 6-9.)
VCR is Plugged in.
TV is turned on and set to the VCR
channel (CH3 or CH4).
Insert a cassette with record tab.
VCR power comes on automatically.
Push VCR CH A/v or
NUMBERED keys to
select a channel.
* Or, push CH A./W on the
VCR.
• To record from an outside
source, push VCR CH A/W to
select “LINE" (see page 22).
SPEED
Push SPEED to change
current recording speed.
• SP = Standard Play, LP = Long
Play, SLP = Super Long Play.
REC/TIME
Push REC/TIME
to start recording.
• Or, push PLAY and
REC/TIME on VCR.
One Touch Timer Recording (OTR)
The VCR starts recording and turns itself off
at a preset time.
Continue to push REC/TIME to set ^Normal Rec
the recording length. Each Push will
change the stop time as shown.
• “TIMER" lights in the Multi Function Display.
c
4íX)-<-3н)0‘^2н)0^1:30
D
Push STOP to
stop recording.
• Or, push STOP on VCR.
Watching Another TV Program
1 Push VCR/TV while recording is in progress
to turn off the VCR indicator in the Multi
Function Display.
2 Use the TV channel controls to select a
program. The VCR will continue to record
your program while you watch any channel
you choose.
• Switch back and forth between the recording
and viewing channel with the VCR/TV selector.
Selecting Channels at the VCR
1 Turn TV on.
y
- V C R -
y s
Multi Function
Display
If indicator doesn’t light, push VCR/TV to turn it on,
2 Use VCR CH A/T buttons to select channels
for viewing or recording.
• To resume TV control channel selection, push VCR/
TV to turn VCR indicator off, or simply turn VCR off.
Holding down the VCR CH A/T buttons will increase the channel search speed.
Push PAUSE to pause a recording in progress. (After the VCR has been in Pause mode for 5 minutes, it will stop
automatically to protect the tape and video head.)
TTie recording time remaining appears if the DISPLAY button is pushed during OTR mode (See page 16).
19
