SPECIFICATIONS
Satellite Receiver CRD-4500R
IF
Input Frequency:
Input Impedance:
Noise Figure:
Input Signal Level:
Number of Channels:
C-Band
Ku-Band
Bandwidth (-3dB):
Threshold:
Demodulator:
Video
De-emphasis:
Frequency Response:
DG & DP:
Output Impedance:
Output Level:
Composite
Output Impedance:
Output Level:
Frequency Response:
Audio
Subcarrier Audio:
Tuning Range
Bandwidth
Mode
Frequency Response
VC Mode Audio:
Mode
Frequency Response
Output Impedance:
Output Level:
VHF Output
Impedance:
Channel:
Output Level:
LNB Power:
General
Power Source:
Dimensions (W x H x D):
Weight:
Polarizer;
950-1450MHz
75 ohms
15dB max.
-65—30dBm
24ch
32ch
27MHz, typical
less than 8dB C/N
PLL Demodulator
525 lines, CCIR Rec 405-1
10kHz-4.2MHz, ±1dB
5%, 5°
75 ohms
1 Vp-p, typical
75 ohms
1 Vp-p, typical
lOkHz-BMHz, ±2dB
5.2~8.6MHz
150kHz, 280kHz
Mono
50Hz-15kHz, ±2dB
Stereo/Mono
20Hz~18kHz, ±2dB
600 ohms
1 Vp-p, typical
75 ohms
CH3/CH4
65dB jLiV, typical
18V DC, 300mA
117V AC±10%
14 3/i6”x2 '‘5/-,6"x11’
(360 X 75 X 280mm)
9 3/4 lbs. (4.4kg)
Servo output
Specifications subject to change without notice.
Power Supply CRD-4500P
Output:
Sensor Type;
Power Consumption:
Dimensions (WxHxD);
Weight:
36V DC, 4A max,
for 5 minutes
Hall effect:
Reed switch:
Optical switch
46W
7 3/32”X2 ■'3/ie”x 11”
(180x75x280mm)
11 Vs lbs. (5.0kg)
MASTER PASSWARD; 3872
