CONNECTIONS
CAUTION:
Inproper connection ot accessories (or connection to incompatible equipment) may damage your unit. All connections should
be made with the power supply unplugged.
[T| I
CONNECTION OF OUTDOOR UNIT
• Insert the 25 PIN connector of the power supply [CRD-4500P], to the connector terminal located on the rear panel of
the satellite receiver tCRD-4500R] and tighten the locking screws.
• Connect LNB down converter to the receiver and connect the polarizer and actuator to power supply.
HALL SENSOR AND OPTICAL TYPE ACTUATOR
HALL SENSOR AND
OPTICAL TYPE ACTUATOR
Motor
Sensor
36
c
V 36
) c
V Gf
> c
+5
> C
.V PU
> C
c
LSE G
> C
4SE
NO
)
CRD-4500R
SATELLITE RECEIVER
REED SWITCH TYPE ACTUATOR
- 1 1 -
