Connections
For Australia and NewZealand
For others
FM outdoor antenna :
(not included)
For Australia and NewZealand
AM outdoor antenna
(not included)
For others
(included)
AM outdoor antenna
(not included)
(included)
You may need an outdoor antenna if you use this system in a moun
tainous region or inside a reinforced-concrete building, etc.
FM outdoor antermo ^
Disconnect the FM indoor antenna if an FM outdoor antenna is in
stalled.
© Remove a piece of the outer vinyl insulator,
d) Twist the shield braid.
(a) Expose the core wire.
Fori'AustraliamndtNewZealand.:
The configuration of FM Antenna terminal is different.
An outdoor antenna should be installed by a qualified technician
only.
AM outdoor antenna Eü
Connect the outdoor antenna without removing the AM loop anten
na. Run 5 to 12 m of vinyi-covered wire horizontally along a window
or other convenient location.
niwia
When the unit is not in use, disconnect the outdoor antenna to pre
vent possible damage that may be caused by lightning. Never use
an outdoor antenna during an electrical storm.
.......................
ш
®For details, refer to the instruction manual of the units which are to
be connected.
•This example shows how to connect an analog player with the
PHONO OUT/LINE OUT switch.
•When units other than those described below are to be connected,
please consult with your audio dealer.
•Only an analog player with a built-in phono equalizer can be con
nected.
•Set the switch to the "LINE OUT” position at the back of the analog
player.
