Technkaf spedfkations
AMPLIFIER SECTION
RMS power output
THD 10%, both channels driven
100 W per channel (60)
1 kHz continuous power output
THD 1%, both channels driven (DIN)
70 W per channel (60)
Input sensitivity
AUX 250 mV
Input Impedance
AUX 10kO
AMPLIFIER SECTION
RMS power output
THD 10%, both channels driven
70 W per channel (60)
1 kHz continuous power output
THD 1%, both channels driven (DIN)
50 W per channel (60)
Input sensitivity
AUX 250 mV
Input Impedance
AUX 10kO
FM TUNER SECTION
Frequency range
87.50-108.00 MHz (50 kHz steps)
Sensitivity
S/N25dB 1.5 pV
Antenna terminal(s) 750 (unbalanced)
AM TUNER SECTION
Frequency range 522-1629 kHz (9 kHz steps)
Sensitivity
S/N 20 dB 500 pV/m
CASSETTE DECK SECTION
Track system
Heads
Record/piayback
Erasure
Motor
Recording system
Erasing system
Tape speed
4 track, 2 channel
Solid permalloy head
Double gap ferrite head
DC servo motor
AC bias 100 kHz
AC erase
4.8 cm/s
Dolby NR off
Dolby NR on
Frequency response (+3, ~6 dB at DECK OUT)
NORMAL (TYPE 1) 35 Hz-14 kHz
HIGH (TYPE II) 35 Hz-14 kHz
S/N
50 dB (A weighted)
60 dB (CCIR)
For Australia and NewZealand
50 dB (A weighted)
For others
Dolby NR off
50 dB (A weighted)
Dolby NR on 60dB(CCiR)
Wow and flutter 0.18% (WRMS)
Fast forward and rewind times
Approx. 120 seconds with C-60 cassette tape
CD SECTION
Sampling frequency 44.1 kHz
Decoding 16 bit linear
Beam source/wave length
Semiconductor laser/780 nm
Number of channels Stereo
Frequency response
20 Hz-20 kHz (+1,-2dB)
Wow and flutter Below measurable limit
Digital filter 8fs
D/A converter MASH (1 bit DAC)
SPEAKER SECTION
Type
Speaker(s)
Super woofer
Woofer
Midrange
Tweeter
Impedance
Input power
4 way speaker system
17 cm cone type
12 cm cone type
6 cm cone type
Piezo type
Total 60
Total 160 W (Music)
Total 80 W (DIN)
Output sound pressure level 84 dB/W (1.0 m)
Cross over frequency
200 Hz, 3.5 kHz
Frequency range 45 Hz-22 kHz (-16 dB)
55 Hz-20 kHz (-lOdB)
Dimensions (WxHxD) 250x330x310 mm
Weight
4.6 kg
SPEAKER SECTION
Type
Speaker(s)
Woofer
Midrange
impedance
Input power
2 way 2 speaker system
14 cm cone type
3 cm cone type
Total 60
Total 100 W (Music)
Total SOW (DIN)
Output sound pressure level 84 dB/W (1.0 m)
Cross over frequency
200 Hz
Frequency range 48 Hz-22 kHz (-16 dB)
58 Hz-20 kHz (-lOdB)
210x330x259 mm
3.5 kg
Dimensions (WxHxD)
Weight
GENERAL EfflaCTige
Power supply
For United Kingdom, Australia and
NewZealand
For others
Power consumption
Dimensions (WxHxD)
Weight
AC 230-240 V, 50 Hz
AC 230 V, 50 Hz
133W
270x336x347 mm
7.5 kg
GENERAL
Power supply
For United Kingdom, Australia and
NewZealand
For others
Power consumption
Dimensions (WxHxD)
Weight
AC 230-240 V, 50 Hz
AC 230 V, 50 Hz
156W
270x336x347 mm
7.1 kg
Notes:
1 . Specifications are subject to change
without notice.
Weight and dimensions are approximate.
2 . Total harmonic distortion is measured by
the digital spectrum analyzer.
MASH is a trademark of NTT.
movm0 or
shipping this system
Prepare the system as described below to pre­
vent damage to the mechanism,
1. Remove all CDs,
2, Press CD.
3. Press ■ for 5 more seconds.
The display will change from “WAIT" to
“LOCKED” to "GOOD BYE” and finally
"ZZZ", Then, the unit will be turned OFF
automatically. (This will set the so-called
“shipping mode”.)
4, Unplug the stereo.
The shipping mode will turn OFF automaticatty
when you turn the power ON the next time.
THIS MUSIC SYSTEM iS CAPABLE OF RECEIVING THE NEW AM STEREO BROAD­
CASTS FROM THE AM BAND RADIO STATIONS. HOWEVER LIKE MANY MUSIC
SYSTEM CURRENTLY AVAILABLE ON THE MARKET IT WILL REPRODUCE THIS AM
STEREO SIGNAL ONLY IN AM MONO, WHICH, IN EFFECT, IS OF NO LESSER QUAL­
ITY THAN YOUR EXISTING AM MONO MUSIC SYSTEM.
Matsushita Electric Industrial Co., Ltd.
Centra! P.O. Box 288, Osaka 530-91, Japan
RQT4175-2B
