SPECIFICATIONS
AUDIO SECTION
• Minimum RMS Output Power
(8 a . 20 Hz to 20 kHz, 0.04% THD)..................................... 73 W + 75 W
• Dynamic Power (IHF)
(8/6/4/2 0) .................................................................. 105/125/150/178 W
• Maximum Output Power [Etu'ope model only]
(1 kHz. 0.7% THD, 4 £2) .................................................................. 105 W
• lEC Outptit Power [Europe model onH]
(1 kHz, 0.04% THD, 8 0) ........................ ".......................................... 84 W
• Power Band Width
(0.08% THD. 35 W, 8 O)................................................. 10 Hz to 50 kHz
• Damping Factor (SPEAKERS A)
20 Hz to 20 kHz, 8 Q.......................................................... 150 or more
• Maximiun Output Power (EIA.T)
[Asia and General models onK]
(1 kHz. 10% THD. 8 n> ......................................................................115 W
• Maximum Input Signal
PHONO (1 kHz, 0.04% THD)........................................... 70 mV or more
CD. etc. (1 kHz. 0.04% THD) ............................................. 2.2 V or more
• Frequency Response
CD, été (20 Hz to 20 kHz) ..........................................................0 ± 0.5 dB
CD, etc. PURE DIRECT ON (10 Hz to 100 kHz)......................0 ± 1.0 dB
• RIAA Equalization Deviation
PHONO........................................................................................... ±0.5 dB
• Total Harmonic Distortion
PHONO to OUT (REC)
(20 Hz to 20 kHz, 3 V) ...................................................... 0.02% or less
CD, etc. to SPEAKERS
(20 Hz to 20 kHz, 35 W, 8 £2) .......................................... 0.02% or less
• Signal to Noise Ratio (ÎHE-A Network)
PHONO (5 mV input shorted) ........................................... 82 dB or more
CD, etc. (185 mV input shorted) ..................................... 108 dB or more
• Residual Noise (IHF-A Network)
PURE DIRECT ON........................................................................ 100 pV
• Gain Tracking Error (0 to -60 dB) ...............................................2 dB or less
• Input Sensitivity/Input Impedance
PHONO...................................................................................... 2.5mV/47kn
CD, etc........................................................................................ i85mV/47ka
• Output Level/Output Impedance
OUT (REC).......................................................... 185mV/1.2kf2orless
SUB WOOFER OUTPUT..........................................................4 V/T .2 kO
ZONE 2 OUTPUT............................................................ 185 mV/l .2 kO
• Headphone Output/Impedance
(Input 1 kHz, 185 mV, 8 £2,0.015% THD)
CD, etc................................................................................... 0.47 V/390 Q
• Channel Separation
CD, etc. (5.1 k£2 input shorted, LTOkHz)................... 65/50 dB or more
• Tone Control Characteristics
BASS
Boost/Cut (20 Hz)........................................................................... ±10 dB
Turnover Frequency........................................................................ 350 Hz
TREBLE
Boost/Cut (20 kHz)......................................................................... ±10 dB
Turnover Frequency^.................................................................... 3.5 kHz
• Continuoiis Lottdness Conhol
Attenuation (1 kHz) .......................................................................... -30 dB
VIDEO SECTION
• Video Sigmi] Type
[U.S.A,, Canada and General models] ................................ NTSC
[Other models] ........................................................................
'PAL
• Signal lo Noise Ratio .................................................50 dB or more
• Frequency Response (MONITOR OUT)
Composite................................................. 5 Hz to 10 MHz. -3 dB
FM SECTION
• Tuning Range
lU.S.A. and Canada models] ........................... 87.5 to 107.9 MHz
1 Asia and General models] ..... 87.3/87.50 to 107.9/108.00 MHz
lOthermodelsI ............................................. 87.50 to 108.00 MHz
• Usable Sensitivity (IHF)....................................... 1.0 pV (11.2 dBf)
• Signal lo Noise Ratio (IHF)
Mono/Stereo............................................................... 76 dB/70 dB
• Harmonic Distortion (1 kHz)
Mono/Stereo................................................................. 0.2%/0.3A/
• Stereo Separation (1 kHz) ....................................................... 45 dB
• Frequency Response........................... 20 Hz to 15 kHz. +0.5/-2 dB
AM SECTION
• Tuning Range
IU..S.A, and Canada models].............................. 530 to 1710 kHz
[Asia and General models] ................ 530/531 to 1710/1611 kHz
lOther models] .................................................... 531 to 1611 kHz
• Usable .Sensitivity............................................................. 300 iiV/m
GENERAL
• Power Supply
[U.SA. and Canada models] .............................. AC 120 Vi 60 Hz
[zAsia model] ..................................AC 220./230-240 V. 30/60 Hz
[General model]................ zAC 110/120/220/230-240 V, 30/60 Hz
[zAustralia model] ............................................. zAC 240 V. 30 Hz
[Europe model]................................................... zAC 230 M 50 Hz
• Power Consumption............................................................... 180 W
• Standby Power Consumption.................................................. O.i W
• Ma^xinium Powder Consumption [General model only]
(8 Q H kHz. 10% THD) ..................................................... 400 W
• AC Outlets
[zAiistraiia model] ............................. 1 (Total 100 W maximmn)
[General model] ................................... 2 (Total 50 W maxiinmn)
[Other models] ................................... 2 (Total 100 W maximimi)
• Dimensions (W x H x D) ................................ 435 x 151 x 308 mm
(17-1/S"x5-15..'1CA 12-1/8^')
• Weight ............................................................. 8.7 kg (19 lbs. 3 oz.)
Specifications are subject to change without notice.
