Installation Guide
WARNING
This installation information is designed for experienced Installers and is not in­
tended for non-technical individuals. It does not contain warnings or cautions of po­
tential dangers involved in attempting to install this product.
Any attempt to install this product in a motor car by anyone other than qualified in­
staller could cause damage to the electrical system and could result in serious per­
sonal injury or death.
□ Installation Hardware
No. Item Diagram Q’ty
© Mounting collar 1
© Hex. nut (5 mm0) 1
Rear support strap 1
0 Tapping screw
(5 mm0x16 mm)
1
(D Mounting bolt (5 mm0) 1
® Power connector 1
© Removable face plate
case
1
Trim plate 1
CD Mounting spring (R) 1
0 Mounting spring (L) 1
0 Flat-head screw
(5 mm0x6 mm) 2
Lock cancel plate 2
□ Overview
This product should be installed by a professional.
However, if you plan to install this product yourself,
your first step is to decide where to install it.
The instructions in these pages will guide you
through the remaining steps:
(Please refer to the “WARNING” statement
above.)
• Identify and label the car wires.
• Connect the car wires to the wires of the power
connector.
• Install the unit in the dashboard.
• Check the operation of the unit.
If you encounter problems, please consult your
nearest professional installer.
Caution:
• This unit operates with a 12 V DC negative
ground auto battery system only. Do not at­
tempt to use it in any other system. Doing so
could cause serious damage.
Before you begin installation, look for the items
which are packed with your unit.
• Warranty Card... Fill this out promptly.
• Panasonic Servicenter List for Service Directory
...Keep for future reference In case the product
needs servicing.
• Installation Hardware. ..Needed for in-dash in­
stallation.
□ Required Tools
You’ll need a screwdriver, a 1.5 V AA battery, and
the following:
12 V DC
Test bulb
Electrical
tape
Side-cut
pliers
