Name of Controls Functions
(Remote Control Unit)
Point the remote control unit at the main unit’s sensor. page 24)
tPWR] (SOURCE)
• Switches on/off the power. page 26)
• Selects a source. page 26)
[BAND]
• Selects a band. page 28)
• Pause CD playing. page 31)
[RET] (RETURN)
• Returns to the previous display in menu setting
mode.
[MENU]
• Enters the menu setting mode.
• Returns to the regular mode during menu play setting.
[FACE]
• Selects the button color and display
brightness. {■* page 39)
[S-A] (Spectrum Analyzer)
• Selects the Spectrum Analyzer display
pattern. page 43)
[DISP] (Display)
• Changes the display.
(^ pages 28, 31,35)
[DIM] (DIMMER)
• Changes the dimmer levei.
(^ page 43)
fa
tD'”CD”GDi
a
© CD
TeSeT S w ! t
steel
[#] (NUMBER)
• Enters the number input mode.
(^ pages 31, 35)
[/v] [V] (Hour/minute/disc)
• Seiects (vertically) or adjusts an op­
eration or item.
• Adjusts the clock. (^ page 27)
• Seiects disc. (^ page 34)
[<11>] (Track/tune)
• Selects (horizontally) or adjusts an
operation or item.
• Selects or searches frequency/track.
(^ pages 28, 31,34)
[SET]
• Determines an operation or item.
[0] to [9]
• Memorizes broadcast stations. (^ page
• Selects track/disc. (^ page 31,35)
[4] (RAND0M)/[5] (SCAN)/[6| (REPEAT)
• Selects listening item. (^ pages 32,36)
29)
[ ^ ] [ v ] V O L (Volume)
• Adjusts the sound volume.
[MUTE]
• Lowers the volume.
(^ page 27)
page 27)
[J>](S-HDB)
• Sets the Super High Definition Bass
sound. (^ page 39)
Back side
Lithium battery (included)
Position B
Battery Installation O
Remove the battery holder.
Pull the battery holder by the position B while pushing posi­
tion A in the direction indicated by the arrow.
O Install the battery on the battery holder.
As shown in the figure on the right, fit the battery into the battery
holder with the “-i- ” side facing up while pressing on position A.
0 Insert the battery holder.
Push the battery holder back into its original position.
Battery Notes Battery holder
Remove and dispose of an old battery immediately. Position A
Battery Information: • Battery type: Panasonic lithium battery (CR2025) (included)
• Battery life: Approximately 6 months with normal use (at room temperature)
Caution: Improper use of batteries may cause overheating, an explosion or ignition, resulting in injury or a
fire. Battery leakage may damage the unit.
• Do not disassemble or short the battery. Do not throw a battery into a fire.
• Keep batteries away from children to avoid the risk of accidents.
• Be careful to observe proper local disposal rules when you dispose of batteries.
CQ-DF802U
23
