Removing a paper misfeed (8A^)

Paper exit area

I

$

1

® Open front panel

@ Move the sorter to the left if installed

(See P 46)

(D Open exit cover

® Turn the left paper clearing knob

(f) Remove misfed paper

Left Paper Clearing Knob

3

Caution: this fuser area may be hot

® Open the fuser guide

® Check that no misfed paper is

remaining

(3) Close the fuser guide

4

® Close exit cover

@ Close front panel

fusing area may be hot, so use caution when removing misfed paper

■ The front panel must be opened prior to opening the exit cover

52
