Figure 3-1 – Cisco 4490 User Manual
Page 50
Chapter 3 Installing the Cisco Global Site Selector 4490
Tools and Parts Required
3-4
Cisco Global Site Selector 4490 Hardware Installation Guide
78-15755-01
Figure 3-1
Four-Post Rack Installation Kit
Note
The right and left slide rails are identical.
1
Slide rail assemblies (2)
2
M3.5 screws with lock washers (3)
3
M4 screws (6)
4
M6 screws (10)
5
Clip nuts (10)
6
Cage nuts (10)
7
Cage nut insertion tool (1)
83198
1
2
3
4
5
6
7
