131
Parameter Function
Network Mode Includes multiple access, fault tolerance, and load balancing
Default Network
Card Please select eth0/eth1/bond0(optional) after enable
multiple access function
Ethernet Please select eth0/eth1 (optional).after enable multiple
access function.
Note: The 960H series support the above three configurations and supports
functions as multiple access, fault-tolerance and load balancing.
PPPOE
—
Input the PPPoE user name and password you get from the
IPS (internet service provider) and enable PPPoE function.
Please save current setup and then reboot the device to get
the setup activated.
—
Device connects to the internet via PPPoE after reboot. You
can get the IP address in the WAN from the IP address
column.
— Please note if you want to reboot the device please make
sure you have proper reboot right and there is no login user
in current device.
Email
The email interface is shown as in
X463H463H463H
Figure 7-33
X
.
Figure 7-33
Please refer to the following sheet for detailed information.
Parameter Function
SMTP Server Input server address and then enable this function.
Port Input port value here.
User Name The sender email account user name.
