Table 4. IP Settings Definitions
Menu Item Description
Local MAC Address View the MAC address for this 9155
1 Local IP Address Set the IP address for this 9155
2 Subnet Mask Set the subnet mask
3 Gateway IP Address Set the IP address for the gateway
4 Enable BOOTP Mode Enable or disable BOOTP requests
5 Management VLAN Id Set the number for the VLAN
6 Telnet Host Verification Enable or disable authentication when access is by Telnet
6 Static ARP Table Set or change specific IP and MAC addresses
7 Dynamic ARP Table View current IP and MAC addresses
8 Main Menu Returns directly to the Main Menu
Use the Static ARP Table to set specific IP and MAC addresses for up to 10 ports. See Figure 10.
STATIC ARP TABLE
IP Address MAC ADDRESS
1. 172.16.2.7 00-90-37-56-6C-34
2. 172.16.3.23 00-7C-25-33-57-9C
Figure 10. Static ARP Table Screen
To use view, set, or remove an address, follow these steps:
1. From the IP Settings screen, type 6 , "Static ARP Table," and press .
2. At the prompt, type 1 to add an entry or 2 to remove an entry, and follow the prompts.
3. To return to the IP Settings screen, press .
Use the Dynamic ARP Table to view the currently assigned IP and MAC addresses for various ports.
See Figure 11.
DYNAMIC ARP TABLE
IP Address MAC ADDRESS Port IP Address MAC ADDRESS Port
172.16.2.82 00-98-2C-BE-27-01 3
172.16.153.6 00-50-54-C3-33-41 4
172.16.142.1 00 90 27 4F D1 8D 3
Figure 11. Dynamic ARP Table Screen
9155 Network Interface Device 4-7
