4.4 9155 Main Menu
The first screen is the Login Menu. If this is your initial setup and no password has been set, press
at the prompt for the password. Otherwise, type your password and press .
The Main Menu appears after you log in and provides access to all functions for the 9155: setup,
diagnostics, and reports. See Figure 5.
MAIN MENU
1) System
2) Switch Configuration
3) Port Information
4) Reports
5) Diagnostics
6) Utilities
7) Logout
Figure 5. 9155 Main Menu
4.5 System Menu
The System Configuration menu provides access to most configuration options for the 9155. To
access the System Configuration menu, see Figure 6 and Table 3 and follow these steps:
1. From the Main Menu, type 1 , "System Configuration," and press . The System
Configuration menu appears.
2. To return to the Main Menu, press .
SYSTEM
1. System Information
2. Module Information
3. IP Settings
4. Host Table/SNMP Settings
5. Notification Settings
6. Security Configuration
7. Account Configuration
8. Management Packets Filter
9. Trap Configuration
10. SNTP Settings
11. Main Menu
Figure 6. System Menu
Table 3. System Menu Option Definitions
Selection Description
1. System Information Shows general information about the 9155
2. Module information Shows fan, temperature, power supply status, and port module
status for the 9155
3. IP Settings Shows access control information; you can set options
