EdgeAccess Universal Chassis System
4-36 L351 10/100BASE Media Converter
4.9 Layer 2 Statistics
Use the Layer 2 Statistics screen to view data transfer protocol statistics on the L351. See Figure
4-33. To view layer 2 statistics, follow these steps:
1. From the Main Menu, type 5, Layer 2 Statistics, and press . The Layer 2 Statistics
screen appears.
2. To reset the counters, press .
3. To view additional statisctics for the remote module, press . At that screen, you can
access remote RMON statistics; tyep 2 and press .
4. When you finish checking the statistics, press to return to the Main Menu.
Figure 4-33. Layer 2 Statistics Screen
4.10 Utilities
Use the Utilities screen to set the time and date, update modem, SLIP, or PPP parameters, or to run
the diagnostic PING. See Figure 4-34 and Table 4-12. Options 5 through 9 are available only when
the L351 is in a standalone enclosure. To access the Utilities screen, follow these steps:
1. From the Main Menu, type 6 , Utilities, and press . The Utilities menu appears.
2. To return to the Main Menu, press .
---------------------LAYER 2 STATISTICS (CURRENT)---------------------
Local Local Remote 9145 Remote 9145
User Port Ext Port Ext Port User Port
Link State ** DOWN ** UP UP ** DOWN **
Speed/Duplex N/A 100M/FULL 100M/FULL N/A
Frames Sent 0 0 183920 0
Frames Rcvd 0 183921 0 0
Bytes Sent 0 0 11770880 0
Bytes Rcvd 0 11770944 0 0
Undersize < 64 0 0 0 0
Oversize > 10000 0 0 0 0
Frames > 1518 0 0 0 0
Frames Sent Rate 0/s 0/s
Frames Rcvd Rate 0/s 1/s
Last Counter Reset: 2 days 03:05:41
Select [(N) Remote RMON Statistics, (M) More Remote Statistics,
(E) Error Counters, (CTRL-T) Raw Counters, (CTRL-R) Reset Counters]:
-------------------Hit 'ESC' to return to previous menu---------------
