CANOGA PERKINS L351 10/100BASE Media Converter - Manual (Page 37)

EdgeAccess Universal Chassis System
L351 10/100BASE Media Converter 4-13
Table 4-2. Functional Configuration Option Definitions
Menu Item Description
1) Configuration Option Control Set the L351 to follow settings in software and ignore SW2
and SW3 settings
2) User Port Speed/Duplex Set the User Port to specific data rate and duplex options, to
automatic rate and duplexing, or disable it
3) RMTF Enable or disable RMTF if SBMC is enabled or RMTF/LLE if
SBMC is disabled
4) Link Loss Fwd Enable or disable LLF
5) Remote Configuration Set the software settings on the remote end of the L351
Figure 4-8. Remote Configuration Menu
Figure 4-9. Remote Functional Configuration Screen
--------------------------REMOTE FUNCTIONAL CONFIGURATION-------------
User Port Speed/Duplex Link Down
Ext Port Speed/Duplex 100M/Full
1) User Port Setting 100M/Full
2) Ext Port Setting 100M/Full
3) RMTF Disabled
4) Link Loss Fwd Disabled
5) Flow Control Disabled
6) Maximum Frame Size 10000
7) Sideband Management Enabled
Select [1-7]:
-------------------------------Messages-------------------------------
-----------------------------REMOTE CONFIGURATION---------------------
1) Functional Configuration
2) VLAN Configuration
3) VLAN ID Translation Table
4) P-Bit Translation Table
5) Port Filters
6) Local Configuration
Select [1-6]:
-------------------------------Messages-------------------------------
