CANOGA PERKINS L351 10/100BASE Media Converter - Manual (Page 20)

EdgeAccess Universal Chassis System
3-2
Table 3-1. L351 LEDs
LED Status Description
Off No power
Green Normal operation
Amber System self-test
Amber blinking Downloading file
STA
Red Major alarm
Off SBMC is disabled
Green SBMC is enabled
Amber System self-test
CFG
Red Configuration error
LNK/Rx (User Port) Off No link
Green Link Established
Green blinking Receiving activity
Amber System self-test
Off No transmission activity
Green Transmission activity
Amber Port in standby mode or system self-test
TX (User Port)
Red Transmission disabled due to LLF or port disabled
Off 10 M data rate 100
Green 100 M data rate
Off Half duplex mode FDX
Green Full duplex mode
Off No link
Green Link Established
Green blinking Receiving activity
Amber System self-test
LNK/Rx
(Extension Port)
Red Receiving Remote Fault
Off No transmission activity
Green blinking Transmission activity
Amber Port in standby mode or system self-test
Tx (Extension Port)
Red Transmission disabled due to LLF
