EdgeAccess Universal Chassis System
4-16
L351 10/100BASE Media Converter
4.5.3 Trap Configuration
Traps are messages to alert network management about conditions. The DMM logs the traps and the
DMM or Model 1020 transmits them by SNMP to the network manager. At the Trap Configuration
screen, enable or disable traps individually or use the Master Trap Control to enable or disable all
traps. See Figure 4-14. To configure traps, follow these steps:
1. From the Main Menu, type
1
, System Configuration, and press
Configuration menu appears.
2. From the System Configuration menu type 3, Trap Configuration, and press
3. At the Trap Configuration menu, type the number for a trap and press
Note: Master Trap Control enables or disables all traps. The factory default is Log Only.
4. Press
5. To return to the System Configuration menu, press
Figure 4-14. Trap Configuration Screen
-----------------------------TRAP CONFIGURATION----------------------
1) Master Trap Control Log Only
2) Local User Port Link Traps Both Log And Send
3) Remote User Port Link Traps Both Log And Send
4) Extension Port Link Traps Both Log And Send
5) Remote Fault Received Traps Both Log And Send
6) Link Loss Forwarding Traps Both Log And Send
7) Link Loss Echo Traps Both Log And Send
8) Cold Start Traps Both Log And Send
9) Authentication Traps Both Log And Send
10) Side Band Mgmt Channel Traps Both Log And Send
11) Diagnostics Traps Both Log And Send
12) Configuration Traps Both Log And Send
13) Power/Fan/Temperature Traps Both Log And Send
14) SFP Traps Both Log And Send
15) Alarm Input Traps Both Log And Send
Select [1-15]:
-------------------------------Messages-------------------------------
