EdgeAccess Universal Chassis System
L351 10/100BASE Media Converter 4-21
Figure 4-18. Host Access Table Screen
The Trap/Notification Destination Table lists information about, and options to set up, hosts to
receive notification of traps and alarms. To access the Trap/Notification Destination Table screen, see
Figure 4-19 and follow these steps:
1. From the IP/SNMP Configuration menu type 3 and press .
2. At the Trap/Notification Destination Table screen, type 1 to edit a host or 2 to add a host at
the Edit Notification Destination Entry screen, or type 3 to remove a host.
3. To return to the IP/SNMP Configuration menu, press .
Note: To add or edit a host entry, follow the prompts on the notification destination entry screen.
Figure 4-19. Trap/Notification Destination Table Screen
TRAP/NOTIFICATION DESTINATION TABLE
Managing Trap Username/ Security
Host Port Type Community Level
172.16.14.200 163 V1-Trap public N/A
172.16.100.20 162 V2c-Trap public N/A
172.16.142.1 163 V3-Trap public Auth/No Priv
---------------------------HOST ACCESS TABLE--------------------------
Managing Host Telnet FTP SNMP SNMP V1/V2c Rd V1/V2c Wr V1/V2c
IP/Mask Bits Access Access Access Protocol Community Community Access
172.016.150.010/32 All All None N/A N/A N/A N/A
Select [(A)dd, (D)elete, (E)dit, (M)ore]:
-------------------------------Messages-------------------------------
