4.5.4 Alarm Output Configuration
Use the Alarm Output Configuration screen to set any or all alarms to Major, Minor, or Off. See
Figure 4-15 and Table 4-3. To configure alarms, follow these steps:
1. From the Main Menu type
3
, Alarm Output Configuration, and press
Configuration screen appears.
2. Type the number for the alarm you want to set and press
3. Press
Figure 4-15. Alarm Output Configuration Screen
Table 4-3. Alarm Output Definitions
Alarm Description
2) Link Down
Loss of Signal (electrical)/Composite Loss of Signal (optical);
one or both received signals fail; default is Off
3) RMTF
Remote fault received; default is Off
4) LLF
Link loss forwarded to module; default if Off
5) Configuration
Setup errors, including mismatches with other modems; default
is Off
6) Power/Fan/Temperature
Power is low or fan is off; default is Minor
7) SBMC Loss
SideBand management signal lost; default is Off
8) Power-On Self Test
Modem failed when power was turned on; default is Off
9) SFP Transmitter Warning
10) SFP Transmitter Failure
Note: You must enable the Alarm Output item on the System Status & Configuration screen for
these settings to take effect.
--------------------------ALARM OUTPUT CONFIGURATION------------------
1) Factory Defaults
2) Link Down Alarm Minor
3) RMTF Alarm Major
4) LLF Alarm Major
5) Configuration Alarm Off
6) Power/Fan/Temperature Alarm Minor
7) SBMC Loss Alarm Major
8) Power-On Self Test Alarm Major
9) SFP Transmitter Warning Minor
10) SFP Transmitter Failure Major
Select [1-10]:
-------------------------------Messages-------------------------------
