EdgeAccess Universal Chassis System
L351 10/100BASE Media Converter
4-35
Figure 4-31. Link Status Screen
4.8 System
Alarms
Use the System Alarms screen to view alarms and faults on the L351. See Figure 4-32. To view alarm
status:
1. From the Main Menu, type 4, System Alarms, and press
appears.
2. When you finish checking the Alarm status, press
Figure 4-32. System Alarms Screen
--------------------------------SYSTEM ALARMS-------------------------
Local Remote 9145
Configuration Errors No No
User Port *** Down *** *** Down ***
Extension Port Up Up
User Port Remote Fault N/A N/A
Ext Port Remote Fault No No
Link Loss Echo No
Link Loss Fwd Ext->User No No
Link Loss Fwd User->Ext No No
Side Band Mgmt Channel OK OK
User SFP Transmitter N/A N/A
Extension SFP Transmitter N/A N/A
Chassis Management N/A
Alarm Relay Inputs N/A
Power Supply Primary OK OK
Power Supply Secondary N/A
Fan N/A
Chassis Temperature N/A
-------------------Hit 'ESC' to return to previous menu---------------
-----------------------------LINK STATUS------------------------------
Local Remote 9145
Chassis Standalone
Slot N/A
User Port Link Down Link Down
Extension Port Link Up Link Up
SFP Status:
User SFP Rx Power N/A N/A
User SFP Tx Power N/A N/A
Extension SFP Rx Power N/A N/A
Extension SFP Tx Power N/A N/A
Link Loss From Local Ext Tx To Remote Ext Rx N/A
Link Loss From Remote Ext Tx To Local Ext Rx N/A
Press ESC to return to previous screen
-------------------------------Messages-------------------------------
