OFNA Racing Ultra GTP MBX - Manual (Page 26)

R 0
1
Screw
Ceme
nt
37380
6mm
Ball Joint
* Insert shock ball end
into arm.
* Insert shock ball end
into arm.
3 x 15mm
Screw
3 x 15mm
Screw
3 x 15mm Screw
3mm Nylon Locknut
3 X 8mm Washer
3mm
Nylon
Lock Nut
3 x 8mm
Washer
3 x 8mm
Washer
6mm ²y ÀY
ASSEMBLY OF THE FRONT AND REAR SHOCKS
ONTO THE SHOCK TOWER
Assembly of the right and left hand side
are the same.
Assembly of the right and left hand side
are the same.
Screw
Ceme
nt
30403
6mm
Ball Joint
3mm
Nylon
Lock Nut
Plastic Washer
Plastic Washer
or
Use CNC Alum Spacer, 4 purchase.
#36507 $4.95
