Assembly of the front gear box onto chassis, Assembly of the front bumper – OFNA Racing Ultra GTP MBX User Manual
Page 16
3 x 10mm
Flat Head
Screw
* A 3 x 10mm flat head screw
are for servo post.
34040
Chassis
R
0
1
ASSEMBLY OF THE FRONT GEAR BOX ONTO
CHASSIS
3 x 25mm
Flat Head
Tapping Screw
3 x 25mm
Flat Head
Tapping Screw
R
0
0
1
1
ASSEMBLY OF THE FRONT BUMPER
4 x 20mm Flat Head
Tapping Screw
4 x 20mm
Flat Head
Tapping Screw
4 x 20mm
Flat Head
Tapping Screw
3 x 10 mm
Flat Head
Screw
3 x 25mm Flat Head
Tapping Screw
34090
Front Bumper, GTP
