Lower Arm Shaft
3mm
E-Ring
3mm
E-Ring
* Insert drive shaft
before assembly. * Do not over tighten
5x5mm set screw.
5x5mm
Set Screw
30152
Upper arm Shaft
90021
3mm
E-Ring
3x25mm
Cap Screw 3mm
Flange Nut
36905
Caster Angle
Adjuster
* o change
the caster angle .
use adjuster t
Caster angle will
become bigger. Caster angle will
become less.
Assembly of the right and left hand side
are the same.
R R
3 mm E-Ring
5 x 5mm
Set Screw
3mm
E-Ring
0
1
R R
3 x 3mm Set Screw
3 mm E-Ring
0
1
ASSEMBLY OF THE FRONT ARM ONTO GEAR BOX
ASSEMBLY OF THE CASTER ADJUSTER
0
1
S c re
w
C
e m
e n t
3 x 20mm
Cap Screw
M3 Flange Nut
( Steel )
